3BHE019959P201AEND:C每套关键压缩机组配备本特利3500框架 本特利bently冗余的3500/15电源模块 本特利bently3500/22M瞬态数据接口模块（RJ45网络接
每台机组的本特利3500框架内配置相应的3500/25键相 往复式压缩机曲轴箱振动、十字头振动、以及轴承振动振均配置相应的3500/70M监测器模块 活塞杆位置测点，需配置相应的3500/72M监测器模块
往复式压缩机气缸动态压力配置相应的3500/77M监测器模块
轴承温度和气阀温度测量点，需配置相应的3500/60、/61、/62或/65监测器模块
每个监测通道配置D立的两个继电器输出通道；采用3500/32（4通道）或3500/33（16通道）继电器模块本特利bently一个3500/92Modbus通讯网关,对于工作在危险区的机组，接入现场信号的3500监测器模块要带有内置安全栅；并且3500框架内要配置3500/04本安接地模块。
本特利bently3500旋转机械振动保护仪表和状态监测系统的产品质量严格遵循美国API670标准。
本特利振动监测培训教程，本教程的主要内容：位移传感器噪声源
噪声是一种你不需要的信号，但多数情况下，在测量过程中，噪声是无法避免的。尽管在测量过程中无法除噪声，但可以将噪声降低到Z小程度，使其不影响你对信号的分析。要做到这一点，就要了解噪声的来源和特征。噪声是一种不合乎需要的信号成分，它可以歪曲数据，妨碍你从数据中提取机器状态信息的能力，包含的信息与机器的状态无关。噪声可以从测量系统的一个环节引入振动信号，但系统各个部分对噪声的敏感程度不同。本特利位移传感器包括bently3300系列的涡流传感器探头。
位移传感器噪声源
1·安装：传感器支架振动5、偏差（runout）–机械偏差
位移传感器噪声源
偏差（runout）–电偏差合金元素不均匀导电性不均匀导磁性不均匀轴材料局部应力集中轴上存在局部磁化区域
位移传感器噪声源
偏差（runout）与运行时间–短时间机械偏差和电偏差是稳定的
位移传感器噪声源
偏差（runout）与运行时间–中等时间热力参数和工艺参数发生变化位移传感器噪声源
偏差（runout）与运行时间–长时间某些噪声源（锈、腐蚀和局部磁化区等）发生变化
位移传感器噪声源
Each key compressor unit is equipped with Bentley 3500 frame
Bently redundant 3500 / 15 power module
Bently bently3500 / 22m transient data interface module (RJ45 network interface)
The Bentley 3500 frame of each unit is equipped with corresponding 3500 / 25 Keyphasor module
Reciprocating compressor crankcase vibration, crosshead vibration and bearing vibration are equipped with corresponding 3500 / 70m monitor modules
The corresponding 3500 / 72m monitor module shall be configured for the piston rod position measuring point
Reciprocating compressor cylinder dynamic pressure configuration corresponding 3500 / 77m monitor module
Bearing temperature and air valve temperature measurement points shall be equipped with corresponding 3500 / 60, / 61, / 62 or / 65 monitor modules
Corresponding 3500 / 42m monitor module shall be configured for gearbox shell vibration and motor pad vibration
Each monitoring channel is configured with two relay output channels of vertical D; The 3500 / 32 (4-channel) or 3500 / 33 (16 channel) relay module Bently is used as a 3500 / 92 Modbus communication gateway. For the unit working in the hazardous area, the 3500 monitor module accessing the field signal shall be equipped with a built-in safety barrier; And 3500 / 04 intrinsically safe grounding module shall be configured in the 3500 rack.
The product quality of Bently 3500 rotary machinery vibration protection instrument and condition monitoring system strictly complies with the American API 670 standard.
Bentley vibration monitoring training course, the main content of this course: displacement sensor noise source
Noise is a signal you don't need, but in most cases, noise is unavoidable in the measurement process. Although the noise cannot be removed during the measurement process, the noise can be reduced to a small level Z so that it will not affect your analysis of the signal. To do this, it is necessary to understand the source and characteristics of noise. Noise is an undesirable signal component, which can distort data and hinder your ability to extract machine state information from the data. The information contained is irrelevant to the state of the machine. Noise can be introduced into the vibration signal from one part of the measurement system, but each part of the system has different sensitivity to noise. Bently displacement sensors include Bently 3300 series eddy current sensor probes.
Noise source of displacement sensor
1. Installation: vibration of sensor support 5. Runout - Mechanical deviation
Noise source of displacement sensor
Runout – electrical deviation: alloy elements are non-uniform, conductivity is non-uniform, magnetic conductivity is non-uniform, local stress of the material is concentrated, and there is local magnetization area on the axis
Noise source of displacement sensor
Runout and run time – short time mechanical and electrical deviations are stable
Noise source of displacement sensor
Runout and running time - the noise source of displacement sensor when thermal and process parameters change in medium time
Runout and running time – some noise sources (rust, corrosion, local magnetization zone, etc.) change for a long time
Noise source of displacement sensor
